Hafei Minyi Mini Truck Parts
CHINA HAFEI RUIYI HFJ1011G,ZHONGYI, MINYI MINI TRUCK
HAFEI ZHONGYI HFJ6371B, NEW ZHONGYI HFJ6376, XINYI , MINYI HFJ6370, NEW MINYI HFJ6390, HFJ6391, LUZUN,JUNYI)
HAFEI LOBO,SAIMA AUTO PARTS DISTRIBUTOR
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
1 | 胶管(HOSE) | 465QA-1000093-01 | 1 |
2 | 胶管(HOSE) | 465QA-1000094-01 | 1 |
3 | 卡箍(CLIP) | 465Q-1000092-01 | 2 |
4 | 三通支管(JOINT 3 WAY) | 465Q-1000820-01 | 1 |
5 | 卡箍(CLIP) | 462-1000080 | 4 |
6 | 胶管(HOSE) | 465QA-1000079-02 | 1 |
7 | PCV阀总成(PCV ASSY) | 465Q-1014800 | 1 |
1 | 油轨总成(FUEL RAIL ASSY) | 465QA-1104950-B | 1 |
2 | 螺栓(BOLT) | 462-1000810 | 2 |
3 | 真空软管夹子总成 (VACCUM HOSE CLAMP ASSY) | 465QA-1000850 | 1 |
4 | 软管环箍(PIPE BAND) | QC/T 620-1999 Q67516 | 4 |
5 | 高压进油管总成 (PRESSURE INTAKE HOSE) | 465QA-1A-1014700 | 1 |
6 | 高压回油管总成 (PRESSURE RETURN HOSE) | 465QA-1A-1014600 | 1 |
7 | 燃油管总成(FUEL PIPE ASSY) | 465QA-1104900-B | 1 |
8 | 螺栓(BOLT) | GB5789-86 M8X16 | 1 |
9 | 真空软管(VACCUM HOSE) | 465QA-1000064-01 | 1 |
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
1 | 冷却液温度传感器 (COOLANT TEMPERATURE SENSOR) | 462-1A/D-1300800 | 1 |
2 | 螺栓(BOLT) | 462-1000810 | 1 |
3 | 夹子组件(HOOK ASSY) | 465QA-1000870-B | 1 |
4 | 进气温度压力传感器 (MANIFOLD AIR PRESSURE & TEMPERATURE SENSOR) | 465Q/D2-1100800 | 1 |
5 | 进气温度压力传感器插片 (MANIFOLD AIR PRESSURE & TEMPERATURE SENSOR PLATE) | 465QA-1000111-C | 1 |
6-1 | 开槽圆柱头螺钉(BOLT) | GB65-85-M5×8 | 1 |
6-2 | 弹簧垫圈(SPRING SEAT) | GB859-87 5 | 1 |
7 | 小挂钩总成(SMALL CLAMP) | 465QA-1000860 | 1 |
8 | 碳罐控制阀(SOLENOID VALVE) | 465Q/D2-1207850 | 1 |
9 | 螺栓(BOLT) | GB5789-86 M6×12 | 1 |
10 | 碳罐控制阀插片 (SOLENOID VALVE PLATE) | 465QA-1000109 | 1 |
11 | 油气脱附管(GAS PURGE HOSE) | 465QA-1000840-B | 1 |
12 | 卡箍(CLIP) | 465Q-2/D-1000065 | 1 |
13 | 螺钉(BOLT) | GB5789-86 AM6×16 | 4 |
14 | 进气歧管支架 (INTAKE MANIFOLD BRACKET) | 465QA-1A-1000124 | 1 |
图八 进气歧管部分
FIG. 8 INTAKE MANIFOLD
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
15 | 进气歧管总成(INTAKE MANIFOLD ASSY) | 465QA-1008800 | 1 |
16 | 节气门体垫(THROTTLE BODY GASKET) | 465QA-1000048-01 | 1 |
17 | 节气门体总成 (THROTTLE BODY ASSY) | 465QA-1107950 | 1 |
18 | 螺栓(BOLT) | GB5789-86 M6×35 | 3 |
19 | 螺栓(BOLT) | GB5789-86 M6×40 | 1 |
20 | 进气歧管垫 (INTAKE MANIFOLD GASKET) | 465QA-1000041-01 | 2 |
21-1 | 螺母(NUT) | GB6170-86 M8 | 5 |
21-2 | 弹簧垫圈(SPRING SEAT) | GB93-87 8 | 5 |
22-1 | 螺钉(BOLT) | 462-1000253 | 3 |
22-2 | 弹簧垫圈(SPRING SEAT) | GB859-87 8 | 3 |
23 | 发动机前吊耳(ENGINE FRONT HOOK) | 465QA-1000047-A | 1 |
图七 同步齿轮及罩盖部分
FIG. 7 BELT TIMING AND COVER
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
1 | 同步齿形带内盖总成 (TIMING BELT INSIDE COVER COMP) | 465Q-1A-1000802-A | 1 |
2 | 同步齿形带外盖总成 (TIMING BELT OUTSIDE COVER COMP) | 465Q-1A-1000900-A | 1 |
3 | 扁胶圈(GROMMET) | 462-1000025-A | 2 |
4 | 胶圈(GROMMET) | 462-1000026-A | 2 |
5 | 衬套(SPACER) | 462-1000027 | 4 |
6 | 螺钉总成(BOLT ASSY) | 465Q-1000804 | 4 |
7 | 螺钉(BOLT) | 462-1000228 | 6 |
8 | 小挂钩总成(SMALL CLAMP) | 462-1000860 | 3 |
9 | 从动同步齿轮 (CAMSHAFT TIMING BELT GEAR) | 465Q-1A-1000032 | 1 |
10 | 半圆键(KEY) | 462-1000031 | 1 |
11 | 固定螺钉(BOLT) | 462-1000227 | 1 |
12 | 同步齿型带(TIMING BELT) | 465Q-1A-1000035-B | 1 |
13 | 张力调节轮总成(TENSIONER ASSY) | 462-1000901-03 | 1 |
14 | 张力螺套 (TENSIONER PLUG) | 462-1000030 | 1 |
15 | 弹簧支架(SPRING BRACKET) | 462-1000029 | |
16 | 张力弹簧(TENSIONER SPRING) | 462-1000028 | 1 |
图七 同步齿轮及罩盖部分
FIG. 7 BELT TIMING AND COVER
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
17 | 螺桩(SCREW) | 462-1307201 | 1 |
18 | 螺钉(BOLT) | 462-1000224-B | 1 |
19 | 弹簧垫圈(WASHER SPRING ) | GB93-87 8 | 1 |
20 | 垫圈(WASHER) | 462-1000226 | 1 |
21 | 加热器软管夹子(SOFT TUBE CLAMP) | 465Q-1000073 | 1 |
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
1 | 凸轮轴分总成(CAMSHAFT ASSY) | 465QA-1006810-D | 1 |
1-1 | 凸轮轴(CAMSHAFT) | 465QA-1006001-D或 465QA-1006001-01 | 1 |
1-2 | 传感轮(SENSOR WHEEL) | 465QA-1006003 | 1 |
2 | 封油皮碗总成(OIL SEAL CAMP) | 462-1006900-A | 1 |
3 | 凸轮轴止推片(CAMSHAFT THRUST PLATE) | 462-1003013 | 1 |
4 | 一字槽沉头螺钉 (ROCKER ARM SHAFT SCREW) | 462-1003206 | 2 |
5 | 气门摇臂轴总成 (VALVE ROCKER SHAFT COMP) | 462-1007901 | 2 |
6 | 一字槽沉头螺钉 (ROCKER ARM SHAFT SCREW) | 462-1003205 | 10 |
7 | 气门摇臂总成(VALVE ROCKER -ARM) | 462-1007900 | 8 |
8 | 气门摇臂轴弹簧(ROCKER ARM SPRING) | 462-1007008 | 8 |
9 | 气门调整螺钉(VALVE ADJUSTING SCREW) | 462-1007001 | 8 |
10 | 螺母(VALVE ADJUSTING NUT) | 462-1007201 | 8 |
11 | 进气门(INTAKE VALVE) | 465QA-1007009 | 4 |
12 | 排气门(EXHAUST VALVE) | 465QA-1007008 | 4 |
13 | 气门弹簧(VALVE SPRING) | 465QA-1007012 | 8 |
14 | 气门弹簧座(VALVE SPRING RETAINER) | 465QA-1007013-B | 8 |
图六 摇臂–气门–凸轮轴部分
FIG. 6 ROCKER-VALVE-CAMSHAFT
序号 NO. | 名 称 DESCRIPTION | 件 号 PART NO. | 数量 QTY. |
15 | 气门卡簧(VALVE COTTER) | 465QA-1007014 | 16 |
16 | 弹簧垫圈(VALVE SPRING SEAT) | 465QA-1007011-B | 8 |
17 | 气门油封总成(OIL SEAL) | 465QA-1007920 | 8 |
FASTWIN HAFEI AUTO PARTS WEBSITE:
FASWIN HAFEI AUTO PART LABEL:
Each Parts will be labeled Fastwin design:
( Parts No.:+ Parts Name (Russian & Spanish & Arabic)+Qty + PI No.)
FASTWIN HAFEI AUTO PARTS PACKAGE
FASTWIN HAFEI AUTO PARTS WAREHOUSE:
FASTWIN HAFEI AUTO PARTS FAQ:
Q1: Which auto parts do Fastwin focus?
A1: We mainly deal Chinese brand vehicle as bellows:
Hafei & Chana & Dfsk & Saic Wuling & Chevrolet N200.N300 & Chery Karry
Chery & Geely & Lifan & Byd & Jac Veloce & Brilliance Auto
Great Wall & Havel & Zotye & Dadi & ZX Auto.
Jac & Dongfeng & Jmc & ,Foton & Yuejin
Q2: What is FASTWIN MOQ?
A2: Our MOQ is USD5,000 Per one order total amounts. For each item qty it is ok to 1pcs or any pcs.
Q3: What is FASTWIN payment terms?
A3: Air order: 100% T/T Advanced;
Sea order: We accept 30% T/T Advanced. 70% will be paid before shipping or L/C at sight
A4: How about the delivery time?
Q4: For air order: 7-10 days after receiving total amounts
For sea order: 25~30 days after received 30% advanced
Q5: Will U help us to supply cataes with price list
A5: As there are many car model with different cataes for chinese brand vehicles. All prices are fluctuated frequently, so please send us detail inquiry by excel list with english parts name & parts OEM number or car & parts pictures as you can supply.
Q6: What’s your warranty policy?
A6: 9 months warranty from the date of B/L.For long business.
We accept reasonable claim for aftermarket services!
Q7.: Which Markets are FASWIN Specially
A7.: We have good experience for Russian Markets, Middle-East Markets & Latin America and so on Q8: Can you sell chinese brand parts with original packing or car logo?
Q8: Can you sell chinese brand car parts with original packing or car logo?
A8: Sorry to tell U that we cann’t ! We prefer to deal business in a legal way based on Intellectual property rights & customs’ rules!
If U feel interest to order HAFEI ZHONGYI Car Spare Parts, HAFEI RUIYI Car Part, HAFEI MINYI Auto Parts, HAFEI LOBO Auto Spare Parts, HAFEI SAIMA Car Parts Wholesale, China HAFEI LUZUN Parts ,China HAFEI JUNYI Car Spare Parts, Spare Parts for HFJ1011G Car, HAFEI HFJ6371 HFJ6376 Body Parts, HAFEI XINYI Auto Parts Spare Parts for China HAFEI Car,HAFEI MINYI TRUCK PARTS and so on. Pls contact us!
