图二 气缸体部分
FIG. 2 BLOCK CYLINDER
| 序号
NO. |
名 称
DESCRIPTION |
件 号
PART NO. |
数量
QTY. |
| 14 | 定位套（PLUG） | 462-1000015 | 2 |
| 15 | 水套盖板
(WATER JACKET PLATE） |
462-1002014 | 1 |
| 16 | 水套盖板垫
（WATER JACKET PLATE GASKET） |
462-1002013 | 1 |
| 17 | 螺钉（BOLT） | 462-1000228 | 4 |
| 18 | 变速器上机匣隔板
（CLUTCH HOUSING UPPER PLATE） |
465QA-1000054 | 1 |
| 19 | 变速器下隔板总成
（CLUTCH HOUSING DOWN PLATE） |
462-1701811-A | 1 |
| 20 | 机油滤清器总成（OIL FILTER） | 465Q-1017950 | 1 |
| 序号
NO. |
名 称
DESCRIPTION |
件 号
PART NO. |
数量
QTY. |
| 1 | 气缸盖（CYLINDER HEAD） | 465QA-1003800 | 1 |
| 2 | 十字槽平圆头螺钉（BOLT） | 462-1000243 | 1 |
| 3 | 节流嘴（OIL VENTURI PLUG） | 462-1003006-A | 1 |
| 4 | 夹子（BRACKET） | 462-1000068-B | 1 |
| 5 | 气缸垫总成（CYLINDER HEAD GASKET） | 465QA-1000800-01 | 1 |
| 6 | 定位套（PIN） | 462-1000015 | 2 |
| 7-1 | 螺钉（BOLT） | 462-1000215-B | 10 |
| 7-2 | 垫圈（GASKET） | 462-1000214 | 10 |
| 8 | 气门室罩壳（CYLINDER HEAD COVER） | 465QA-1007017 | 1 |
| 9 | 气门室罩隔板（BREATHER PLATE） | 462-1007015 | 1 |
| 10 | 气门室罩隔板垫
（BREATHER GASKET） |
462-1007016 | 1 |
| 11 | 螺钉（BOLT） | 462-1000228 | 8 |
| 12 | 气门室罩封严胶垫
（CYLINDER HEAD COVER GASKET） |
462-1000071-A | 1 |
| 13-1 | 螺钉（BOLT） | 462-1000216 | 4 |
| 13-2 | 垫圈（WASHER） | 462-1007802 | 4 |
| 14 | 注油口盖总成（OIL FILLER CAP COMP） | 462-1009800-B | 1 |
图一 缸盖–气门室罩部分
FIG. 1. CYLINDER HEAD- CYLINDER HEAD COVER
| 序号
NO. |
名 称
DESCRIPTION |
件 号
PART NO. |
数量
QTY. |
| 15 | 火花塞总成（SPARK PLUG） | 465QA-3707950 | 4 |
| 16 | 凸轮轴后端盖（CAMSHAFT REAR COVER ） | 465QA-1003011 | 1 |
| 17 | 转接座垫片
（GASKET） |
462-1003010-A | 1 |
| 18 | 圆柱滚子
（PIN） |
6×10Ⅲb GB4661-89 | 2 |
| 19 | 螺钉（BOLT） | GB5789-86M8×25 | 3 |
| 20 | 通气软管接管嘴
（BREATHER TUBE） |
465QA-1007018 | 1 |
| 21 | 凸轮轴位置传感器
（CAMSHAFT PHASE SENSOR） |
465QA-3700820 | 1 |
| 22 | 螺钉（BOLT） | GB5789-86
AM6×16 |
1 |
| 23 | 挂钩总成(CLAMP ASSY) | 462-1000830 | 1 |
FASTWIN HAFEI AUTO PARTS WEBSITE:
FASWIN HAFEI AUTO PART LABEL:
Each Parts will be labeled Fastwin design:
( Parts No.:+ Parts Name (Russian & Spanish & Arabic)+Qty + PI No.)
FASTWIN HAFEI AUTO PARTS PACKAGE
FASTWIN HAFEI AUTO PARTS WAREHOUSE:
FASTWIN HAFEI AUTO PARTS FAQ:
Q1: Which auto parts do Fastwin focus?
A1: We mainly deal Chinese brand vehicle as bellows:
Hafei & Chana & Dfsk & Saic Wuling & Chevrolet N200.N300 & Chery Karry
Chery & Geely & Lifan & Byd & Jac Veloce & Brilliance Auto
Great Wall & Havel & Zotye & Dadi & ZX Auto.
Jac & Dongfeng & Jmc & ,Foton & Yuejin
Q2: What is FASTWIN MOQ?
A2: Our MOQ is USD5,000 Per one order total amounts. For each item qty it is ok to 1pcs or any pcs.
Q3: What is FASTWIN payment terms?
A3: Air order: 100% T/T Advanced;
Sea order: We accept 30% T/T Advanced. 70% will be paid before shipping or L/C at sight
A4: How about the delivery time?
Q4: For air order: 7-10 days after receiving total amounts
For sea order: 25~30 days after received 30% advanced
Q5: Will U help us to supply cataes with price list
A5: As there are many car model with different cataes for chinese brand vehicles. All prices are fluctuated frequently, so please send us detail inquiry by excel list with english parts name & parts OEM number or car & parts pictures as you can supply.
Q6: What’s your warranty policy?
A6: 9 months warranty from the date of B/L.For long business.
We accept reasonable claim for aftermarket services!
Q7.: Which Markets are FASWIN Specially
A7.: We have good experience for Russian Markets, Middle-East Markets & Latin America and so on Q8: Can you sell chinese brand parts with original packing or car logo?
Q8: Can you sell chinese brand car parts with original packing or car logo?
A8: Sorry to tell U that we cann’t ! We prefer to deal business in a legal way based on Intellectual property rights & customs’ rules!
If U feel interest to order HAFEI ZHONGYI Car Spare Parts, HAFEI RUIYI Car Part, HAFEI MINYI Auto Parts, HAFEI LOBO Auto Spare Parts, HAFEI SAIMA Car Parts Wholesale, China HAFEI LUZUN Parts ,China HAFEI JUNYI Car Spare Parts, Spare Parts for HFJ1011G Car, HAFEI HFJ6371 HFJ6376 Body Parts, HAFEI XINYI Auto Parts Spare Parts for China HAFEI Car,HAFEI MINYI TRUCK PARTS and so on. Pls contact us!
